The Ultimate GPS Compass for Competitive Sailors
The Sailteck GPS Compass is engineered for performance racing — delivering critical data with unmatched clarity, even when hiking or trapezing at full stretch. Twin 30mm super-bold displays, pinpoint dual-band GPS accuracy, and a solar-powered design mean you can focus entirely on winning.
Key Features
- Pinpoint GPS accuracy — dual-band ceramic patch antenna, 40cm LEP50, tracks 5 constellations & 30+ satellites
- Twin displays — 220° field of view, optimised for polarised sunglasses, no exposed glass
- Solar powered — with 200 hours of battery backup and integrated wireless charging
- 300 hours of data logging — 1Gbit built-in flash memory for race replay and track export
- Class compliant — dual keymat system: red (full GPS) and grey (class-legal mode)
- Shock & waterproof — IPX8, submersible to 20m, floats in salt and fresh water
- Software upgradeable — free updates via Sailteck Webapp
Functions
- Speed & Max Speed
- Compass heading (1° accuracy)
- Heel & Trim
- Countdown timer & Time of day (GPS atomic time)
- Distance-to-line (with bow and beam offset)
- Tactic display for wind shift detection
- Track file export & race replay
Coming via free software upgrade: Track sharing, Bluetooth sensor support, Race start, Tracker with 2Nm range.
Technical Specifications
| Dimensions | 120 × 95 × 65mm |
| Weight | 270g |
| Display | Twin displays, 30mm digits, 220° FOV |
| GPS | Dual-band L1 & L5, 5 constellations, 40cm LEP50 |
| Sensors | 3-axis magnetometer, accelerometer, gyro — 1° accuracy |
| Data logging | 10Hz, 1Gbit flash, 300 hours storage |
| Power | Solar + 200hr battery, wireless charging |
| Waterproofing | IPX8, submersible to 20m indefinitely |
| Connectivity | Bluetooth 5.0+ |
| Temperature | Operating: 0°C–55°C | Storage: −30°C–+70°C |
